Artikeldata
| art.nr | Gänga | Metall | Plast | D mm | d mm | L mm |
|---|---|---|---|---|---|---|
| 684.07.01 | M 12 + Pg 7 | 14 | 15 | 6 | 4.5 | 15 |
| 684.09.01 | M 16 + Pg 9 + 3/8 NPT | 17 | 19 | 7.5 | 5.5 | 17 |
| 684.11.01 | M 16 + Pg 11 + 3/8 NPT | 20 | 22 | 9.5 | 6.5 | 19 |
| 684.13.01 | M 20 + Pg 13.5 + 1/2 NPT | 22 | 24 | 11.5 | 8.5 | 19 |
| 684.16.01 | M 20 + Pg 16 + 1/2 NPT | 24 | 27 | 13.5 | 11.5 | 19.5 |
| 684.21.01 | M 25 + Pg 21 + 3/4 NPT | 30 | 33 | 17.5 | 15.5 | 23.5 |
| 684.29.01 | M 32 + Pg 29 + 1 + 1 1/4 | 40 | 42 | 24 | 19 | 26 |
| 684.36.01 | M 40 + Pg 36 + 1 1/2 NPT | 50 | 53 | 31 | 25 | 28 |
| 684.42.01 | M 50 + Pg 42 | 57 | 60 | 37 | 30 | 28 |
| 684.48.01 | M 63 + Pg 48 | 68 + 64 | 68 + 65 | 43 | 34 | 28 |
